홈 > 환경시험장비 > 향온항습기 HIFLEX NEO Series
Model FX410N FX420N FX420N
Temp. range -40℃~+100℃(-40℃~+150℃)
Humid. Range 20~98%RH (Refer P8 Temp./Humid. Controllable range)
Temp. ramp-up rate -40℃~+100℃(-40℃~+150℃)
within 40 min within 45 min within 40 min
Temp. ramp-down rate -40℃~+100℃(-40℃~+150℃)
within 40 min within 45 min within 40 min
Temp.rate of change
(ramp-up)		 -26℃~+86℃(-21℃~+131℃)
3.5℃/min 3.0℃/min 4.0℃/min
Temp.rate of change
(ramp-down)		 +86℃~-26℃(+131℃~-21℃)
3.5℃/min 3.0℃/min 3.5℃/min
Variation ±0.3℃/±2.5%RH
Gradient Temp./humid. : 1.5℃/5.0%RH
Variation in space Temp./humid. : 1.5℃/5.0%RH
Internal Dimension
(WxHxDmm)		 600x750x600 700x950x700 1000x1000x800
880x1653x1190 980x1853x1290 3.5℃/min
Power Supply AC200V 3Φ 50/60Hz voltage fluctuation ±10%
Refrigerator DC inverter control Rotary compressor
Model FX710N FX720N FX730N
Temp. range -70℃~+100℃(-70℃~+150℃)
Humid. Range 20~98%RH (Refer P8 Temp./Humid. Controllable range)
Temp. ramp-up rate -70℃~+100℃(-70℃~+150℃)
within 90 min within 90 min within 100 min
Temp.rate of change (ramp-up) -53℃~+83℃(-48℃~+128℃)
2.5℃/min 2.5℃/min 4.0℃/min
Temp.rate of change (ramp-down) +83℃~-53℃(+1288℃~-48℃)
2.0℃/min 2.0℃/min 1.5℃/min
Variation ±0.3℃/±2.5%RH
Gradient Temp./humid. : 1.5℃/5.0%RH
Variation in space Temp./humid. : 1.5℃/5.0%RH
Internal Dimension
(WxHxDmm)		 600x750x600 700x950x700 1000x1000x800
880x1664x1190 980x1864x1290 1280x1914x1390
Power Supply AC200V 3Φ 50/60Hz voltage fluctuation ±10%
Refrigerator DC inverter control Rotary compressor
(Dual refrigeration system)
