AC measurement DC measurement
Resistance measurement Range
1)2 kΩ (1Ω resolution)
2)200 Ω (100mΩ resolution)
3)20 kΩ (10mΩ resolution)
4)2,000 Ω (1mΩ resolution)
5)200 mΩ (100μΩ resolution)
6)20 mΩ (10μΩ resolution)		 200.00kΩ
20.000kΩ
2.0000kΩ
20000Ω
20000Ω
Measurement frequency Fixed at 2KHz
Measurement voltage Less than 20mV(ms)
Event detectable resistance range 10mΩ ~ 2KΩ
Measurement range 10mΩ ~ 3kΩ
Measurement method 4-wire method (Kelvin bridge)
Output open circuit voltage 3.6V±0.4V
Maximum saving times of continuous event detection 20 times/channel
